Case/Gig Bag
Deluxe Hardshell
Included Accessories
Deluxe Hardshell Case, Strap and Certificate of Authenticity.
Artisan Koa Thinline Stratocaster®
Artisan Koa Thinline Stratocaster®
Artisan Koa Thinline Stratocaster®
Details
Summary
Overview
The Artisan Koa Thinline Stratocaster® is an enticing and elegant guitar with everything you'd expect in playability and tone from the Fender Custom Shop. Stunning in look, sound and feel, it has a hollow roasted-ash body with an "F" hole and 4A figured koa top, which makes for an unusually alluring aesthetic and distinctive tone. The 3A birdseye maple neck is sculpted with a comfortable 1960 "oval-C" profile, topped by a beautiful Macassar ebony fingerboard with a compound radius (9.5"-12") and 21 narrow tall frets.
The 11-hole single-ply brown shell pickguard holds three hand-wound Fat '60s pickups, with five-way switching and Strat 1/2 Blender wiring, which lets the player blend in the neck pickup in switch positions 1 and 2 for extra tonal options. Other features include Custom Shop vintage synchronized tremolo, vintage-style tuning machines with brown shell buttons, bone nut, and "wing" string tree with metal spacer. Includes deluxe hardshell case, strap and certificate of authenticity.
Accessories
Body
Body
Roasted Ash
Body Back
Roasted Ash
Body Finish
Nitrocellulose Lacquer
Body Material
Roasted Ash
Body Shape
Stratocaster®
Body Top
4A Figured Koa
Electronics
Bridge Pickup
Custom Shop Hand-Wound Fat '60s Single-Coil Strat®
Controls
Master Volume, Master Tone, Blend
Middle Pickup
Custom Shop Hand-Wound RWRP Fat '60s Single-Coil Strat®
Neck Pickup
Custom Shop Hand-Wound Fat '60s Single-Coil Strat®
Pickup Configuration
SSS
Switching
5-Position Blade: Position 1. Bridge with Neck Blend, Position 2. Bridge and Middle with Neck Blend, Position 3. Middle, Position 4. Neck and Middle, Position 5. Neck
General
Color
Aged Natural
Orientation
Right-Hand
Platform
Custom Shop Electrics
Product Name
Artisan Koa Thinline Stratocaster®, Roasted Ash Body with 4A Figured Koa Top, Ebony Fingerboard, Aged Natural, NOS
Series
Artisan
Hardware
Bridge
Custom Shop Vintage Synchronized Tremolo
Control Knobs
Vintage White
Hardware Finish
Chrome
Neck Plate
4-Bolt with Custom Shop "V" Logo, Serialized
Pickguard
1-Ply Tortoiseshell
Pickup Covers
Vintage White
String Trees
Single-Wing with Tall Metal Spacer
Strings
Nickel Plated Steel (.010-.046 Gauges)
Switch Tip
Vintage White
Tuning Machines
Vintage Style with Tortoise Shell Buttons
Measurements
Fret Size
Narrow Tall
Scale Length
25.5" (648 mm)
Neck
Fingerboard Material
Round-Laminated Ebony
Fingerboard Radius
9.5" to 12" Compound Radius
Neck Finish
Tinted Nitrocellulose Lacquer
Neck Material
3A Roasted Birdseye Maple
Neck Shape
'60s Oval "C"
Number of Frets
21
Nut Material
Bone
Nut Width
1.650" (42 mm)
Position Inlays
Mother of Pearl Dot
String Nut
Bone
